| Specification |
| Testing scope | 90° |
| Testing distance | 30CM |
| Background light | white31.5asb,yellow315asb |
| Visual target | 0.08asb---10000asb(0-51DB) |
| Target size | GoldmannⅠ, II ,III,IV,V |
| Visual target stimulation time | 200ms |
| Visual target interval time | Standard and custom |
| Threshold policy | Macula,10-2,24-2,30-2,60-4,nasal side |
| Upper threshold policy | C-40,C-64,C-76,FF-81,FF-120,FF-135…… |
| Special detection strategy | Esterman monocular,Esterman binocular,upper36°screening,blind point
testing |
| Yellow-blue testing | Standard 440nm blue visual target + 315asb OG530yellow background
brightness |
| Visual target | Red ,blue |
| Dynamic policy | Standard dynamic,blind dynamic,dark spot dynamic ,straight line
dynamic |
| Custom policy | Static custom dynamic custom |
| Pupil size measurement | Auto |
| Fixation monitoring | Physiological blind spot monitoring,eye position monitoring,eye
position moving alarm,eye tracking curve |
| Environment light testing | Auto |
| Analysis software | reliability analysis , single report, triple report, GHT glaucoma
semi vision report, GPA glaucoma developing analysis, VFI analysis,
Blue-yellow analysis |
| System | Win7 above |
| Others |
| Size | 412mm(length)* 497mm(width)* 513mm(height) |
| Wight | 17kg |
| Power | 100-240V HZ:50-60Hz |
details:
1.Aspherical design, compact and humanize features, even when tested
to 90 degrees, the patient's feeling is still very comfortable.
2.Built-in physiological blind spot detection, eye position video
detection, eye position deviation alarm, and eye position deviation
flexion line ,allow the operator to align and track the position of
the patient's eyes and provide real-time assessment of eye gaze
3.Standards SWAP blue-yellow visual field examination,sensitive to
earlier visual field defects
4.Scientific and intelligent interactive inspection strategy, 30°
range visual field inspection only takes 3 minutes
5.7 kinds of analysis: reliability analysis, single-report
analysis, multi-report analysis, glaucoma half-field analysis,
glaucoma progression analysis, VFI visual field index
analysis;blue-yellow visual field analysis
6.Half-field analysis designed for glaucoma, making glaucoma
diagnosis easier
7.Analysis of glaucoma progression, very subtle progression is more
visible and continues to indicate new progression
8.Digital Map, Grayscale Map, Population Deviation, Population
Deviation Probability Map, Mode Deviation, Mode Probability Map
Company Introduction
Focusing on the two major public health problems of adolescent
myopia and elderly ophthalmology, our company researches new
diagnostic and treatment equipment for ophthalmology, develops
low-cost applicable technology products, realizes
industrialization, reduces the cost of social medical and health
system, and serves the strategic needs of national health.The company always adhere to the "high-tech,new vision" for the enterprise development
concept.We have a strong technical force, has been awarded 11 patents, and
obtained 13,485 quality system certification.Bio has established an efficient marketing team and a perfect
after-sales service system to provide medical equipment with the
highest cost performance and meticulous service.
